北米Model "A1760BE-A" EDITED: 2020/ 10/ 1
& Temporary spare tires
S12AA15
For U.S. and Canada For Mexico
Temporary spare tire size T145/70D17 T135/70D18 205/50R17 205/45R18
Temporary spare tire inflation pressure
(recommended cold tire inflation pressure)
60 psi (420 kPa, 4.2 kgf/cm
2
) 33 psi (230 kPa, 2.3 kgf/cm
2
) 38 psi (260 kPa, 2.6 kgf/cm
2
)
Wheel nut tightening torque
89 lbf·ft (120 N·m, 12 kgf·m)*
1
*
2
*1: This torque is equivalent to applying approximately 88 to 110 lbf (40 to 50 kgf) at the end of the wheel nut wrench. If you have tightened the wheel nuts
by yourself, have the tightening torque checked at the nearest automotive service facility as soon as possible.
*2: For the wheel nut tightening procedure, refer to “Changing a flat tire” F9-4.
& Brake disc
S12AA18
If you need information on the usage limit value of brake discs and the method for measuring them, consult your SUBARU dealer.
Specifications/Specifications
12-9
