北米Model "A1760BE-A" EDITED: 2020/ 10/ 1
Maintenance tips
S11BI
Some clips and fender linings must be
removed before replacing the air cleaner
elements or specific bulbs.
& Removing and reinstalling
clips
S11BI01
! Removing clips
S11BI0101
There are several types of clips used for
your vehicle.
! Type A clips
S11BI010101
1. Turn the clips counterclockwise using
a flat-head screwdriver until the center
portion of the clip is raised.
2. Remove the clips with a flat-head
screwdriver using leverage.
3. Remove the entire clip by pulling it up.
! Type B clips
S11BI010102
! Type C clips
S11BI010103
1. Pull out the center portion of the clip
using a flat-head screwdriver as shown in
the illustration.
2. Pull the protruded center portion to
remove the entire body of the clip.
Maintenance and service/Maintenance tips
11-6
