北米Model
"A1760BE-A"
EDITED:
2020/
10/
1
Fuses
and
circuits
S12AB
&
Fuse
panel
located
in
the
passenger
compartment
S12AB01
Fuse
panel
Fuse
rating
Circuit
1
20
A
R.FOG
TRAIL
2
7.5
A
METER
IG
3
15
A
DOOR
LOCK
4
10
A
IG2
5
Empty
6
7.5
A
MIR
7
15
A
UNIT+B
8
7.5
A
STOP
9
7.5
A
WIPER
DEICE
10
7.5
A
D-OP+B
1
1
7.5
A
TURN
IG
12
15
A
UNIT
IG1
13
20
A
12
V
PLUG
14
10
A
T
AIL
CLEARANCE
15
10
A
BKUP+B
16
7.5
A
ILM
17
15
A
SEA
T
HTR
18
10
A
LAMP
IG
19
Empty
20
10
A
CIGAR
21
10
A
ST
ART
22
7.5
A
A/C
IG
Specifications/Fuses
and
circuits
12-10
443
445
