Your vehicle is equipped with four lower
anchorages (bars) and three upper an-
chorages (tether anchorages) for accom-
modating such child restraint systems.
! Lower anchorages
S01AG070101
WARNING
Do not connect two or more lower
hooks onto the same anchorage
(bar).
Two lower anchorages (bars) are provided
for installing a child restraint system on the
rear seat window-side seating positions.
Lower anchorages (bars) for window-side
seating positions may be used for a seat in
the center seating position if a child
restraint system manufacturer’s instruc-
tions permit and specify using anchors as
far apart as those in this vehicle. Each
lower anchorage is located where the seat
cushion meets the seatback.
! Tether anchorages
S01AG070102
The tether anchorages (upper an-
chorages) are provided at the locations
shown in the above illustration. For details,
refer to “Top tether anchorages” F1-34.
! To install a child restraint system
using lower and tether an-
chorages
S01AG070103
To install a child restraint system using
lower and tether anchorages, perform the
following procedure.
WARNING
Before installing a child restraint
system, be sure to confirm that the
seatback is securely locked into
place. Otherwise, in an accident,
Seat, seatbelt and SRS airbags/Child restraint systems
1-32
