910R/950R/950T/970T - RECEIVER 17
DISPLAY
910R/950R/950T/970T - RECEIVER 17
DISPLAY
Signal Strength
Signal strength is shown by bars
at top of display and in numeric
display.
Gain
Gain (amount of signal
amplification) is shown by bars
below signal strength indicator.
Gain increases to the right.
