Section 11
ILLUSTRATIONS AND PARTS LIST
103
11.13 MOISTURE DRAIN ASSEMBLY- AIR-COOLED
key part
number description number quantity
1 insert, nylon tubing 1/4"od 02250052-841 2
2 tube, nyl .25od x .040" w 02250054-861 1
3 locknut, n4 conduit sealing 02250071-362 4
4 valve, solenoid 2wnc mo 1/4 200# n4 (I) 02250125-674 1
5 timer, rep cyc 120vac 02250144-630 1
6 valve, ball 1/4" npt 047115 1
7 strainer, v-type 300psix1/4 (II) 241771 1
8 nipple, brass hex 1/4"-npt 249537 3
9 nipple, conduit 1/2 x 1.5" 250007-169 1
10 connector, 1/4"tube x 1/4"npt 250018-428 1
11 elbow, 1/4" tube x 1/4" npt 250018-430 1
12 clamp, tube 1/2" 250025-633 2
13 screw, self-drill 1/4 x 3/4 834504-075 2
14 bulkhead, pipe 1/4" npt 841500-004 1
15 conduit, csa flex 1/2" 846315-050 1
16 elbow, 45deg lq-tite 1/2 846500-050 2
17 elbow, entrance 1/2 847715-050 1
(I) For maintenance on solenoid valve no. 02250125-674, order repair kit no. 02250125-823, and replace-
ment coil no. 0250125-861.
(II) For maintenance on strainer no. 241771, order repair kit no. 241772.
PLEASE NOTE: WHEN ORDERING PARTS, INDICATE THE SERIAL NUMBER OF COMPRESSOR
