Section 3
SPECIFICATIONS
31
Figure 3-2D Piping and Instrumentation- LS-200 and VCC-200 Water-cooled with Supervisor Controller
key part
number description number quantity
01 fltr, air h.d.inlet 12" 02250059-096 1
02 vlv ,inl 6" pop w/bypass LS-200S 02250145-632 1
03 motor - 1
04 compressor unit - 1
05 tnk,sep ls20 leak-free 02250125-995 1
06 sep, air/oil primary LS-200 02250146-962 1
07 sep, air/oil secondary LS-200 02250146-963 1
08 vlv, rlf 3/4" 200# 550scfm 02250097-349 1
09 vlv, min press 2-1/2"sae 02250129-374 1
10 aftercooler, wc 6" x 36" 043008 1
11 clr, oil/water 6x36 1-5/8"sae 02250120-863 1
12 sep, wtr d-h 2"fnpt 1/4" drain 02250144-632 1
13 element, thermal valve 175ºF 049542 1
•element, thermal valve 190ºF 250028-762 1
14 fltr, fl 1-5/8"sae str thrd con 02250054-605 1
15 sw, vac 22"wc n4 6ft cable 5a 02250078-249 1
16 p, rtd 100ohm platinum 12ft 250039-909 2
17 xdcr, press 0-250psi 1-5vdc n4 02250078-933 4
18 strainer, v-type 300psi x 1/4 241771 3
19 valve, shuttle 1/4"(dbl chk) 408893 2
20 valve, pressure regulator 250017-280 1
21 vlv, sol 32no 1/4 235# n4 02250125-657 2
22 valve 2-way pneuctl 1/2"npt 02250100-042 1
23 orifice, .031 02250132-934 1
24 plug, sight glass 1-7/8"sae 02250097-611 2
25 vlv, ball 3/4"sae-m x 1/2"npt-f 02250098-303 1
26 fltr, assembly genisis fltr 02250117-782 2
27 glass, sight/orf blk-sae 02250126-129 2
28 orf, plug brass 1/8"npt x 1/32" 02250125-774 2
29 switch, press no 10psi 250017-992 1
30 valve, ball 1/4"npt 047115 1
31 vlv, sol 2wnc mo 1/4 200# n4 02250125-674 1
SCD DRAIN (OPTIONAL):
40 valve, ball 1/2"npt 047117 1
41 valve, ball 1/4"npt 047115 1
42 drn, electric condensate-scd400 02250130-866 1
VCC-200 MODEL:
43 valve, pressure reg 250017-280 1
44 spiral valve - 1
45 orifice,.031 02250132-934 1
SUMP HEATER (OPTIONAL):
46 htr, sump ls-20 1250w 120v 02250069-938 1
Part varies by model.
Omit item #23 with VCC-200 model.
Continued on page 33
