SECTION 5 PRINCIPLE OF OPERATION
91
5.46 WIRING DIAGRAM—POWER CIRCUIT RC 150 (110/120-1-50/60-A, 208/230-1-50/60-A)
A: RUN WINDING
B: START WINDING
C: MOTOR PROTECTION
A01: CONTROL CIRCUIT TRANSFORMER
B01: MAIN TERMINAL BLOCK
F1: A01 PRIMARY PROTECTION
K01: COMPRESSOR CONTACTOR
K10: FAN CONTACTOR
K40: WATER MOTOR
M01: COMPRESSOR
M10: FAN MOTOR
M40: WATER MOTOR
S01: MAIN SWITCH
