Cyclone MKV 2 Multimedia Enclosure
Page 9.
Version 1.2
Back View:
1 DC IN 12V Power port.
2 Component YPbPr component video output
3 AV Out Composite video output.
4 Optical Optical audio output to connect to a surround
sound system.
5 HDMI High definition video output port. Used to display
high quality video and audio.
6 LAN 10/100 network port to connect the media player
to a wired network.
7 USB USB 2.0 port. Used for file transfers when
connected to a PC.
8 USB Host USB Host port to connect to multiple external
storage devices.
① ③ ④ ⑤ ⑥ ⑦ ⑧
②
