APPENDIX
B
Sun XVR-600 Graphics Accelerator
Specifications
This appendix provides I/O port specifications for the Sun XVR-600 graphics
accelerator.
■ “I/O Port Specifications” on page 45
■ “DVI Video Output Port” on page 46
■ “Stereo Output Port” on page 48
I/O Port Specifications
The external I/O ports are accessible through the I/O connectors on the
Sun XVR-600 graphics accelerator backplate (
FIGURE B-1).
FIGURE B-1 Sun XVR-600 Graphics Accelerator I/O Connectors
The Sun XVR-600 graphics accelerator has the following external I/O ports:
■ Stereo framelock DIN7 connector
■ DVI-I connector
Stereo framelock
DVI-I connector
connector (DIN7)
