Appendix B Sun XVR-600 Graphics Accelerator Specifications 47
15 GND Return: +5V, Hsync, Vsync
16 Hot Plug Detect
17 TMDS Data0—
18 TMDS Data0+
19 TMDS Data0/5 shield
20 No connect
21 No connect
22 TMDS Clock shield
23 TMDS Clock+
24 TMDS Clock—
C1 Analog Red
C2 Analog Green
C3 Analog Blue
C4 Analog Horizontal Sync
C5 Analog GND Return: (analog R, G, B)
TABLE B-1 Sun XVR-600 Graphics Accelerator DVI Video Output Port (Continued)
Pin Signal
