25
Ensure that the DC circuit breaker is disconnected.
step 9 Fix the switch gear with the provided M5 screw or stud.
When 4 or more than 4 battery modules are installed in one base, M5 screw set is
required to secure the switch gear. The stud is mounted on the top of battery
module.
step 10 Connect the harness.
User Manual 4 Mounting
