Sungrow SG50CX-P2 User Manual

81
Classificat-
ion
Parameter
Description
Total Power Factor Power factor of the AC side of the inverter
Gird Frenquency Frequency of the AC side of the inverter
A-B Line Voltage
Line voltageB-C Line Voltage
C-A Line Voltage
Phase A Current
Phase currentPhase B Current
Phase C Current
7.5.3 View Records
Tap Records on the navigation bar to enter the interface showing event records, as shown
in the following figure.
figure 7-7 Records
Fault Alarm Record
Tap Fault Alarm Record to enter the interface, as shown in the following figure.
figure 7-8 Fault Alarm Record
Tap to select a time segment and view corresponding records.
The inverter can record up to 400 latest entries.
Select one of the records in the list and tap the record to view the detailed fault information
as shown in following figure.
User Manual 7 iSolarCloud App

Sungrow SG50CX-P2 Specifications

General

Rated Power	50 kW
Max. DC Voltage	1100 V
MPPT Voltage Range	200 V - 1000 V
Max. Input Current per MPPT	26 A
Number of DC Input Terminals per MPPT	2
Rated AC Output Power	50 kW
Max. AC Output Power	55 kW
AC Nominal Voltage	400 V
AC Voltage Range	310 V - 480 V
AC Grid Frequency	50 Hz / 60 Hz
Grid Frequency Range	45 Hz - 55 Hz / 55 Hz - 65 Hz
Total Harmonic Distortion	<3%
DC Switch	Yes
Protection Class	I
Cooling Method	Smart Forced Air Cooling
Protection Degree	IP66
Maximum Efficiency	98.7%
Topology	Transformerless
Power Factor at Rated Power	0.8 leading to 0.8 lagging
Operating Temperature Range	-25°C to +60°C
Communication	RS485, Ethernet
