Sungrow SG50CX-P2 User Manual

72
Systems equipped with SUNGROW optimizers can only work with SUNGROW com-
munication devices and iSolarCloud App. Please use V2.1.6.20230411 or later ver-
sions of iSolarCloud App.
7.3 Function Overview
The App provides parameter viewing and setting functions, as shown in the following figure.
figure 7-1 App Function Tree Map
7.4 Device Initialization
7.4.1 Requirements
The following requirements should be met:
• The AC or DC side of the inverter is powered-on.
• The mobile phone is within 5 meters away from the inverter and there are no
obstructions in between.
• The Bluetooth function of the mobile phone is enabled.
The inverter can only pair with one phone at a time through Bluetooth.
7 iSolarCloud App User Manual

Sungrow SG50CX-P2 Specifications

General

Rated Power	50 kW
Max. DC Voltage	1100 V
MPPT Voltage Range	200 V - 1000 V
Max. Input Current per MPPT	26 A
Number of DC Input Terminals per MPPT	2
Rated AC Output Power	50 kW
Max. AC Output Power	55 kW
AC Nominal Voltage	400 V
AC Voltage Range	310 V - 480 V
AC Grid Frequency	50 Hz / 60 Hz
Grid Frequency Range	45 Hz - 55 Hz / 55 Hz - 65 Hz
Total Harmonic Distortion	<3%
DC Switch	Yes
Protection Class	I
Cooling Method	Smart Forced Air Cooling
Protection Degree	IP66
Maximum Efficiency	98.7%
Topology	Transformerless
Power Factor at Rated Power	0.8 leading to 0.8 lagging
Operating Temperature Range	-25°C to +60°C
Communication	RS485, Ethernet
