Sungrow SG80KTL User Manual

6 Electrical Connection User Manual
46
Data Logger
RS
485
Data Logger
RS485
RS485-232 converter
RS232
PC
RS232
PC
RS232
RS485
Shielding layer is grounded
120Ω
Inverter 1
RS485
I
N
OU
T
Inverter 2
Inverter n
Multiple inverters in daisy chain
120Ω
RS485
I
N
OU
T
RS485
I
N
OU
T
Inverter Communication connection
Terminating Resistor
n≤15 n>15
Inverter
1
Only out
No
120ohm
Yes
120ohm
Inverter
2~n-1
In and Out
No
120ohm
Inverter
n
In and Out
No
120ohm
Yes
120ohm
6.5.3 RS485 Communication Connection
RS485A/B Bus Connection
Step 1 Lead Network cable through communication cable gland to the
configuration circuit board.
Step 2 Strip off the insulation layer of the communication cable. Connect the A, B,
and GND of RS485 communication cable to corresponding terminals
