2. Methods for Moving the Machine (Fig. 4)
1. Check that the recycling bin is empty, and
empty it if necessary.
2. Check that the brush head and suction
scraper are in the lifting position.
3. Place it on the container rack by using the
chute.
4. Check that the key switch is "OFF" and then
remove the key.
5. Use wooden wedges to fix the machine on
the container rack.
6. Use electronic brake.
3. Upper Control Panel Parts of the Machine
(Fig. 5)
1. Driving Button
2. Liquid Crystal Display Of Batteries
3. Start
4. Dust Absorption
5. Water Quantity Plus
6. Forward / Backward
7. Water Quantity Minus
8. Downloading and Unloading Brush
9. Electric Lock OFF/ON
10. Speed Regulating Knob
11.ECO
12. Uploading and Unloading Brush
4. Lower Control Panel Parts of the
Machine (Fig. 6)
13. Emergency Button
14. Charging Plug
15. Handle Rod of Suction Scraper
