UsageModelOptional device
8
1) Sewing machine
1
Specification
2) Motor
① Servo motor controller
KM-570BL-7 KM-570BL
KM-572BLKM-572BL-7
Purpose
Lubrication Method
Max. Sewing Speed
Max. No. of Stitches
Needle Stroke
Manual
Lap
Automatic
Hook
Needle
Automatic Backtacking Device
Automatic Trimmer
Bed Size
For Heavy Materials (sheet, bags, tents, sofas, etc.)
Automatic Lubrication
2,000spm
9mm
36mm
10.5mm
16mm
2~6mm
Horizontal 2.5x Hook
DP×17 #23 (#14~#25)
568×178mm
② Clutch motor
3) Peripheral automation devices (optional)
AUTO KNEE LIFTING
SYSTEM
PRODUCTION
COUNTER
MATERIAL EDGE
SENSOR
STANDING PEDAL
SCOUN-1
SEDG-1C
SEDG-2C
SPDL-1
SPDL-2
A counting device which indicates the completed quantity on the program unit panel, including added,
subtracted, corrected or remaining quantity along with other performance rates.
A device that senses the edge or thickness of the sewing material to stop the machine without manual
pedaling. Available in two types: SEDG-1C for edge sensing type and SEDG-2C for thickness sensing
type.
An essential device when one person is operating multiple sewing machines. Has different pedals for
acceleration, thread trimming, presser foot and ascending pedal. Types consist of SPDL-1 for fixed
speed and SPDL-2 for variable speed.
When the pedal is placed at reverse step 1, the presser foot is automatically lifted. It is because the
machine has employed the pneumatic cylinder structure.
Presser Foot
Lift
Crossing Between Upper Feed Presser
Foot and Supplementary Presser Foot
Power Supply
Category
16mm (optional) 16mm (optional)
－－
Basic Supply
Basic Supply
1-phase 110/220V,
3-phase 220V
1-phase 110/220V,
3-phase 220V/380V
1-phase 110/220V,
3-phase 220V
1-phase 110/220V,
3-phase 220V
Basic Supply
Basic Supply
－
－
－
－
MODEL
SC55-1B
SC55-1B
SC55-3B
VOLT
1 Phase 110V
1 Phase 220V
3 Phase 220V
WATT
550W
550W
550W
HERTZ
50/60 Hz
50/60 Hz
50/60 Hz
MODEL
HEC-1706(1 Phase)
HEC-1705(3 Phase)
VOLT
110/220V
220/380V
WATT
400W
400W
HERTZ
50/60 Hz
50/60 Hz
