7-24
⑥ X SATIN: Sets the width of a satin stitch in the X direction.
2mm 2mm
[Changing the satin width 2mm on each side]
[After widening]
The setting can increase in increments of 0.1mm on each side. The default is 0 and the range is from 0 to 5.
⑦ Y SATIN: Sets the width of a satin stitch in the Y direction.
Ex) Calling and editing the design in memory #5
X SCALE: 150% START ST: 100 stitches
Y SCALE: 120% X SATIN: 3
ANGLE: 45° Y SATIN: 2
Mirror: Y
Select the design in memory #5 (see
7.4.1) In and Out of Designs).
NO : 5
STITCH : 18294
COLOR : 7
JUMP : 7
1] X_SCALE : 100[%]
2] Y_SCALE : 100[%]
3] ANGLE : 0
4] MIRROR : NO MIRROR
Press
[NOTE]
Basic set-ups are not stored for each design. When a design is called in, all settings revert to the default.
