7-29
■■
Design Trace - tracing outline of the selected design
① This function enables you to quickly check if the X and Y limits of the selected design will fit in the current hoop.
② The arrows in the picture show the path of the design trace. The design will be traced at its furthest points
(maximum and minimum X and Y). If the design is too large for the hoop, the frame stops and the message
“Frame Limit Error”will appear on the screen. To use this function, select and
in the start menu to set the frame limits and set to “YES”in the EMB
FUNCTION.
15. Frame Limit
3. Frame Limit Set
2. Machine SETMachine Set-Up
