SunSynk Hybrid Parity - 2.1. System Diagram

Website: www.sunsynk.com E-mail: sales@globaltech-china.com 10
Output Over Voltage Protection
Integrated
Certifications and Standards
Grid Regulation
UL1741, IEEE1547, RULE21, VDE0126, AS4777, NRS2017, G98,G99, IEC61683,
IEC62116, IEC61727
Safety Regulation
IEC62109-1, IEC62109-2
EMC
EN61000-6-1, EN61000-6-3, FCC 15 Class B
General Data
Operating Temperature Range (℃)
-25~60°C, >45°C Derating
Cooling
Fan
Noise (dB)
<30
Communication with BMS
RS485; CAN
Weight (kg)
32
Size (Length x Width x Height)
670 x 420 x 233 mm
Protection Degree
IP65
Installation Style
Wall-mounted
Warranty
5 years
2.1. System Diagram
