Operating Temperature Range -25~60°C, >45°C Derating
Cooling Natural Cooling
Noise <30dB
Communication with BMS RS485; CAN
Weight 20.5kg
Size (Length x Width x Height) 580 x 330 x 208 mm
Protection Degree IP65
Warranty 5 years
SUNSYNK-3.6K-SG02LP1
Model SUNSYNK-3.6K-SG02LP1
Battery Input Data
Battery Type Lead-acid or Lithium-ion
Battery Voltage Range (V) 40~60V
Max. Charging Current (A) 90A
Max. Discharging Current (A) 90A
Charging Curve 3 Stages/Equalisation
External Temperature Sensor Optional
Charging Strategy for Li-Ion Battery Self-Adaptation to BMS
PV String Input Data
Max. DC Input Power (W) 7000W
Voc Max. (V) 500V
MPPT Range (V) 125~425V
Full Load DC Voltage Range (V) 240~425V
Start-up Voltage (V) 150V
PV Input Current (A) 11A+11A
No. of MPPT Trackers 2
No. of Strings Per MPPT Tracker 1+1
AC Output Data
Rated AC Output and UPS Power (W) 3600W
Max. AC Power (W) 3960W
Peak Power (off-grid) 2 times of rated power, 10 S
AC Output Rated Current (A) 15.7A
Max AC Output Current (A) 18A
Max Continuous AC Passthrough (A) 35A
Power Factor 0.8 leading to 0.8 lagging
Output Frequency and Voltage 50/60Hz; 220/230/240Vac (single phase)
Grid Type Single Phase
Current Harmonic Distortion THD<3% (Linear load<1.5%)
Efficiency
Max. Efficiency 97.60%
MPPT Efficiency 96.50%
Euro Efficiency 99.90%
Protection
PV Input Lightning Protection Integrated
Anti-islanding Protection Integrated
PV String Input Reverse Polarity
Protection
Integrated
Insulation Resistor Detection Integrated
Residual Current Monitoring Unit Integrated
Output Over Current Protection Integrated
Output Shorted Protection Integrated
Output Over Voltage Protection Integrated
Certifications and Standards
Grid Regulation
VDE 0126, AS4777, NRS2017, G98, G99, IEC61683, IEC62116,
IEC61727,
