RD1699:2011, XP C15-712-3:2019-05
Safety Regulation IEC62109-1, IEC62109-2
EMC EN61000-6-1, EN61000-6-3
General Data
Operating Temperature Range (℃)
-25~60°C, >45°C Derating
Cooling Natural Cooling
Noise (dB) <30
Communication with BMS RS485; CAN
Weight (kg) 20.5
Size (Length x Width x Height) 580 x 330 x 208 mm
Protection Degree IP65
Installation Style Wall-mounted
SUNSYNK-5K-SG01/03LP1
Model SUNSYNK-5.5K-SG01/03LP1
Battery Input Data
Battery Type Lead-acid or Lithium-ion
Battery Voltage Range 40~60V
Max. Charging Current 120A
Max. Discharging Current 120A
Charging Curve 3 Stages/Equalisation
External Temperature Sensor Optional
Charging Strategy for Li-Ion Battery Self-Adaptation to BMS
PV String Input Data
Max. DC Input Power 6500W
PV Input Voltage 370V (100V~500V)
MPPT Range 125~425V
Full Load DC Voltage Range 240~425V
Start-up Voltage 150V
PV Input Current 11A+11A
No. of MPPT Trackers 2
No. of Strings Per MPPT Tracker 1+1
AC Output Data
Rated AC Output and UPS Power 5000W
Max. AC Power 5500W
Peak Power (off-grid) 2 times of rated power, 10 S
AC Output Rated Current 21.7A
Max AC Output Current 25A
Max Continuous AC Passthrough 35A
Power Factor 0.8 leading to 0.8 lagging
Output Frequency and Voltage 50/60Hz; 220/230/240Vac (single phase)
Grid Type Single Phase
Current Harmonic Distortion THD<3% (Linear load<1.5%)
Efficiency
Max. Efficiency 97.60%
MPPT Efficiency 96.50%
Euro Efficiency 99.90%
Protection
PV Input Lightning Protection Integrated
Anti-islanding Protection Integrated
PV String Input Reverse Polarity
Protection
Integrated
Insulation Resistor Detection Integrated
Residual Current Monitoring Unit Integrated
Output Over Current Protection Integrated
