SunTech ST940 - Page 45

Doc. Title
ST940 User Manual
Concerning:
Rev.
Date (dd-mm-yy)
Page of Pages
Features and how to configure ST940
1.19
0
19-06-15
15
45 of 51
LAT
String
Latitude in degree
LON
String
Longitude in degree
SPEED
String
Speed over the ground in Km/h
COURSE
String
Track angle in degrees
FIX
‘0’ or ‘1’
0: GPS is not fixed
1: GPS is fixed
DISTANCE
String
Moving distance value (Unit : m).
This information will be here only if “ PROT_TYPE = 1”
BATTERY_VOLT
String
Battery voltage
This information will be here only if “ PROT_TYPE = 0”
IMMEDIATE
Digit
0: Report is sent from the memory
1: Report is sent on-line
This information will be here only if “ PROT_TYPE = 0”
MODE
Digit
5: The vehicle went out from the geo-fence that has following ID.
6: The vehicle entered into the geo-fence that has following ID
56 = Magnet Connection Alert
57 = Magnet Disconnection Alert
58 = Low Battery. This information will be here only if “ ADD_INF = 1”
MODEL
DISTANCE
CELL
MCC
MNC
RSSI
LAC
TM_ADV
SATT
SIG_GSM
2 Char
String
String
String
String
String
String
String
String
String
Device Model (According to table model)
Moving distance value (Unit : m).
This information will be here only if “ PROT_TYPE = 0”
Information of Cell ID
Cell ID(4digits hex) + Location Code ID(4 digits hex) + Serving Cell
BSIC(2 digits decimal).
This information will be here only if “ PROT_TYPE = 0”
Information of Mobile Country Code
Information of Mobile Network Code
Information of Signal Strength
Information of Location Area Code
Information of Timing Advance
Number of satellite
Level of GSM signal
<Example>
ST910;Alert;456789;410;20141018;18:30:12;+37.478774;+126.889690;000.000;000.00;0;4.0;1;6002
// PROT_TYPE = 0 and ADD_INF =0
ST910;Alert;456789;410;20141018;18:30:12;+37.478774;+126.889690;000.000;000.00;0;4.0;1;6002;02;0;
0310000100;450;01;-282;70;255;3;0 // PROT_TYPE = 0 and ADD_INF =1
