2.2 Channel Mode
In channel mode, the rig operates in a traditional manner with 6 bands of 40 channels selectable
by the band selector and tuning with the fine and coarse control. In this mode the frequency
step indicator is not shown as per the image below:
2.2.1 Available operating bands
In channel mode, 6 bands are selectable including the UK 27/81 band with correct channel and
frequency readout.
Band Switch Label Band Start Frequency End Frequency
SL Super Low 26.065 MHz 26.505 MHz
LOW Low band 26.515 MHz 26.955 MHz
MID FCC 26.965 MHz 27.405 MHz
HI High band 27.415 MHz 27.855 MHz
SH Super High 27.865 MHz 28.305 MHz
UK UK FM 27/81 27.60125 MHz 27.99125 MHz
2.3 Alpha channels
Alpha channels are inserted automatically in-between normal channels as you turn the channel
selector as per the list below:
... 3 → 3A → 4 → 5 → 6 → 7 → 7A → 8 → 9 → 10 →
11 → 11A → 12 → 13 → 14 → 15 → 15A → 16 → 17 → 18 → 19 → 19A → 20 ...
Alpha channels can be identified by the small A to the right of the channel number as in the
example below:
