DRT35 See Through and Peninsula Direct Vent Gas Fireplace
Figure 54
REFERENCE
Firebox Accessories / Parts
Cat. No. Model No. Description
88L53 FGE Bag of Glowing Embers
80L42 FDVS
Bag of Decorative
Volcanic Stone
Glowing Embers
Bag of Glowing
Embers (rockwool)
Separate into Quarter
Size (separate) Pieces
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
F
D
Bottom View of Logs (in packaging)
C
E
A
B
C
F
A
D
Top View of Logs
E
B
Top View of Logs - Installed
F
E
A
C
B
D
(Valve Access Side)
LOG SET
Catalog Number
H3210
* Item
Description
A
Log, Center
B
Log, Left Rear
C
Log, Right
D
Log, Top Center
E
Log, Top/Left
F
Log, Top/Right
* Item "letters" above correspond to photos on right
LOG SET - IDENTIFICATION
