66
NOTE: DIAGRAMS & ILLUSTRATIONS ARE NOT TO SCALE.
WARNING
Failure to position the parts in accordance with these
diagrams or failure to use only parts specifically
approved with this appliance may result in property
damage or personal injury.
AVERTISSEMENT
Risque de dommages ou de blessures si les pièces
ne sont pas installées conformément à ces schémas
et ou si des pièces autres que celles spécifiquement
approuvées avec cet appareil sont utilisées.
Contact an Authorized Innovative Hearth Products dealer to obtain any of these parts. Never use substitute materials. Use of non-approved parts
can result in poor performance and safety hazards.
Item Part/Cat.No. Qty Description Where Used
SIT Millivolt Only
1 H3357 1 Gas Train Assembly, NG, MV SEE THROUGH
2 H3355 1 Gas Train Assembly, LP, MV PENINSULA
Honeywell Electronic Only
3 H3356 1 Gas Train Assembly, NG, Elecrtr. SEE THROUGH
4 42J32 1 Transformer
SEE THROUGH
Misc. Replacement Parts
5
H3352
1
Burner, Pan All
6
H3353
1
* Electrical kit All
7
J7533
2
Hood, Front
SEE THROUGH
8
J7534
1
Hood, End
PENINSULA
9 93L32 1 Flex Line Gas Connector, FFGC All
10
H4864
2 Glass Enclosure Assembly
35"
SEE THROUGH
11 H7033 1 Glass Enclosure Assembly
22"
SEE THROUGH
12 H3696 Vermiculite, Bag of All
13 H3358 1 Grate Assembly All
14 69L21 4 Latch, Glass Enclosure Panel All
15
H3354
1
Firebox Sub-Floor All
Item Part/Cat. No. Qty Description Where Used
Misc. Replacement Parts
16
H3210
1 Log Set All
17 H3740 8 Nailing Flange
All
18
24M10
1 Orifice, Burner, NG, #37 (.104") SEE THROUGH
19
42M79
1 Orifice, Burner, LP, 1.55mm
(.061")
SEE THROUGH
20 91K94 1 Piezo Igniter (w/wire)
SEE THROUGH
21 27K30 1 OFF/ON Switch, Rocker All
22 H3363 Vent Restrictor All
23 J7424 2 Barrier, Front SEE THROUGH
PENINSULA
24 J7425 1 Barrier, End PENINSULA
26 J7528 Front Face Assembly with Barrier SEE THROUGH
PENINSULA
26 J7529 End Face Assembly with Barrier PENINSULA
REPLACEMENT PARTS LIST - ST/PF
Note: Ordering information for Volcanic Stone, Glowing Embers and Touch-up Paint can
be found on Page 19.
* Electrical Outlet Kit consists of a junction box, 2 screws, a receptacle outlet, an OFF/ON
rocker switch and a snap bushing. Note: All the components in the electrical kit will Not be
used by every model.
Installation and Operation Instructions
900300-00, 02/2015
Innovative Hearth Products
Superior
TM
DRT35 See Through and Peninsula Direct Vent Gas Fireplace
