SuperMax 37x2 - Parts List for SUPER MAX Stand

38 SUPERMAX OWNER’S MANUAL
SUPERMAX STAND ASSEMBLY PARTS LIST
Ref.
Number
Description
Part Number
SM25x2 Both SM37x2
Qty./
Unit
Models
1
HEIGHT ADJUSTMENT HANDLE ASSEMBLY
31-0020
1
2
3/16"x1" ROLL PIN
20-0772
1
3
5/8" I.D. OILITE WASHER
50-3080
2
4
3" PLASTIC COLUMN TUBE CAP
80-4015
2
5
ADJ. SCREW SUPPORT CASTING
30-1112
3
6
1/4"–20x1/2" SOCKET HEAD SET SCREW
10-2804
6
7
5/16"–18x3/8" SOCKET HEAD SET SCREW
10-2903
4
8
PLASTIC CAP
80-4013
3
9
SELF TAPPING SCREW
10-3905
2
10
DEPTH GAUGE POINTER
40-1102
1
11
11
DEPTH GAUGE SCALE
DEPTH GAUGE (NOT SHOWN)
40-1101
94-1654
30-1260HR
1
1
12
DRUM SUPPORT CASTING – SINGLE
– DUAL
30-5106
2
30-5206
2
13
DEPTH LOCK CASTING
30-1112
2
14
INBOARD TABLE SUPPORT CASTING – SINGLE
– DUAL
30-5104
1
30-5204
1
15
5/16"–18 HEX NUT
12-0003
4
16
5/16" SAE WASHER
11-0206
4
17
5/16"–18x3/4" BRASS TIPPED SET SCREW
10-9906
4
18
LOCKING KNOB
81-3132
2
19
OUTBOARD TABLE SUPPORT CASTING – SINGLE
– DUAL
30-5105
30-5205
1
1
20
TABLE MOUNT BRACKET
40-0025
40-4242
2
21
3/8"–16x1" HEX HEAD BOLT
10-0205
18
22
5/16" WROUGHT WASHER
11-9103
37
23
3/8"–16 FLANGE LOCK NUT
12-0209
24
24
INBOARD HEIGHT ADJ. SCREW
30-1212
30-1212HR
1
25
MITER GEAR
20-1101
4
26
1/2" I.D. OILITE BUSHING
50-3107
4
27
27
COLUMN TUBE
COLUMN TUBE
30-1236
30-3044
2
2
28
1/2-13x1/2" SOCKET HEAD SET SCREW
10-8905
2
29
SHAFT COLLAR 1/2" I.D.
20-1103
2
30
TRANSFER ROD
30-1213
30-3117
1
31
MOTOR MOUNT
40-0106
1
32
MOTOR SUPPORT CASTING
30-5107
1
33
3/8"–16x1 1/2" HEX HEAD BOLT
10-9207
9
34
34
LEG CASTING
LEG CASTING
30-1102
30-1103
4
4
35
COLUMN BASE CASTING
30-1101
2
36
LEVELING FEET
20-0655
4
37
3/8"–16 HEX NUT
12-0005
8
38
BASE SUPPORT BRACKET
40-0230
40-4241
1
39
RETAINING RING
20-0752
1
40
OUTBOARD HEIGHT ADJ. SCREW
30-1211
30-1211HR
1
