44 SUPERMAX OWNER’S MANUAL
SUPERMAX DUAL DRUM HEAD ASSEMBLY PARTS LIST (Cont'd)
Ref.
Number
Description
Part Number
Qty./
Unit
SM25x2
Both
Models
SM37x2
46
1/2"–13 HEX NUT
12-0009
1
47
DRIVEN PULLEY
50-0502
2
48
5/16"–18x1/2" HEX HEAD BOLT
10-9101
2
49
BELT GUARD COVER
80-1028
80-1038
1
50
#8-32x1" PHILLIPS FILLISTER HEAD SCREW
10-3107
6
51
COMPRESSION SPRING
20-3268
6
52
5/16"–18x3/4" CARRIAGE HEAD BOLT
10-1203
4
53
#8-32 SQUARE NUT
12-0102
6
54
TENSION ROLLER BASE BKT.
40-0306
2
55
TENSION ROLLER SUSPENSION BKT., RIGHT
40-0302
3
56
TENSION ROLLER SUSPENSION BKT., LEFT
40-0303
3
57
5/16" I.D. OILITE BUSHING
50-3105
6
58
TENSION ROLLER
30-1205
30-3119
3
59
MIDDLE INNER BELT GUARD
41-1028
1
60
#10–24 RETAINING NUT
20-1155
2
61
#10–24x3/8" SLOTTED HEX HEAD SCREW
10-3803
4
62
5/16"–18 FLANGED LOCK NUT
12-0207
6
63
5/16"–18x3/8" SET SCREW (PULLEY)
10-8903
2
64
BELT GUARD PLATE (NOT SHOWN)
41-1010
1
SUPERMAX CONVEYOR & MOTOR PARTS LIST
Ref.
Number
Description
Part Number
Qty./
Unit
SM25
Both
Models
SM37
1
DRIVEN ROLLER
30-3103
30-3104
1
2
1/2" I.D. SQUARE OILITE BUSHING
50-3109
4
3
TAKEUP SLIDE
40-4108
2
4
5/16" SAE WASHER
11-0206
2
5
5/16"–24 FLANGED NUT
12-0308
6
6
WRENCH
40-0375
2
8
TAKEUP BASE BRACKET
40-4107
2
9
3/8"–16x1" CARRIAGE BOLT
10-1302
16
10
5/16"–24x3" STUD
30-1306
2
11
3/8"–16 NYLON INSERT LOCK NUT
12-8005
4
12
3/8" SPRING WASHER
20-1165
8
13
SIDE RAIL
40-4105
1
14
ROLLER SUPPORT BRACKET
40-4109
1
15
RUBBER COVERED DRIVE ROLLER
30-3106
30-3107
1
16
3/8"–16x3/4" CARRIAGE BOLT
10-1301
4
17
3/8" FLANGED LOCK NUT
12-0209
16
18
CONVEYOR BED
40-4101
40-4201
1
19
SIDE RAIL
40-4106
1
(Continued on page 46)
