13
Chapter 1: Introduction
Connector Description
LAN1 - LAN2
LAN3 - LAN4
Gigabit Ethernet (RJ45) Ports)
10G Ethernet (RJ45) Ports
PJ1 4-pin 12V DC Power Connector (To provide alternative power for special enclosure
when the 24-pin ATX power is not in use.)
SLOT7 PCI-E 3.0 X16 Slot
SRW1, SRW2 M.2 Holding Screws
USB 0/1 Back panel USB 3.0 Ports
USB2/3, USB4/5 Front Access USB 2.0 Ports
VGA Back panel VGA Port
USB0/1 Back panel Universal Serial Bus (USB) 2.0 Ports
USB2/3 Back Panel USB 3.0 Ports
USB4 USB Type A Header
USB5/6, USB7/8 Front Panel USB 2.0 Headers
VGA Back Panel VGA Port
