SuperServer E300-8D User's Manual
Quick Reference
Jumper Description Default Setting
JBR1 BIOS Recovery Pins 1-2 (Normal)
JBT1 CMOS Clear Open: Normal, Short: Clear CMOS
JI2C1/JI2C2 SMB to PCI-Exp. Slots Pins 2-3 (Disabled)
JPG1 VGA Enable Pins 1-2 (Enabled)
JPL1 LAN1 Enable Pins 1-2 (Enabled)
JPL2 LAN2 Enable Pins 1-2 (Enabled)
JPL3 LAN3/4/5/6 Enable Pins 1-2 (Enabled)
JPME1 ME Recovery Pins 1-2 (Normal)
JPME2 Manufacturing Mode Pins 1-2 (Normal)
JPTG1 10Gb Ethernet Enable Pins 1-2 (Enabled)
JPUSB1 USB Wakeup Pins 1-2 (Enabled) (For USB0/1 Only)
JWD1 Watch Dog Enable Pins 1-2 (Reset)
Connector Description
BT1 Onboard Battery
COM1 COM1 Header
FAN1 - FAN4,
FANA, FANB
CPU/System Cooling Fans
IPMI LAN Dedicated IPMI LAN Port
I-SATA0 - I-SATA5 Intel SATA Ports (I-SATA0 / I-SATA1 support SuperDOM, I-SATA4 via M.2, I-SATA5 via
Mini-PCIE mSATA)
I-SGPIO1 Serial Link General Purpose I/O Headers
JD1 Speaker (Pins 1-3: Power LED, Pins 4-7: Speaker)
JF1 Front Panel Control Header
JGP1 General Purpose I/O Expander Header
JIPMB1 4-pin External SMbus I
2
C Header (for an IPMI Card)
JL1 Chassis Intrusion Header
JMD1 M.2 PCI-E 3.0 X4 / I-SATA4 Slot
JMP1 Mini PCI-E 2.0 X1 / I-SATA5 Slot
JNVI2C1 NVMe I
2
C Header
JOH1 Overheat LED Header
JPH1 4-pin Power Connector for HDD use
JPI2C1 Power Supply SMBus I2C Header
JPV1 12V 8-pin DC Power Connector
JPW1 24-pin ATX Power Connector
JSD1, JSD2 SATA DOM (Device_On_Module) Power Connectors
JSMB1 SMBus Header
JSTBY1 5V Standby Power Header
JTGLED1 LAN7 ~ LAN8 Activity LED Header
