Supermicro SuperServer E300-8D User Manual

81
Appendix A BIOS Error Codes
Appendix A
BIOS Error Codes
A-1 BIOS Error Beep (POST) Codes
During the POST (Power-On Self-Test) routines, which are performed each time the system
is powered on, errors may occur.
Non-fatal errors are those which, in most cases, allow the system to continue the boot-up
process. The error messages normally appear on the screen.
Fatal errors are those which will not allow the system to continue the boot-up procedure. If
a fatal error occurs, you should consult with your system manufacturer for possible repairs.
These fatal errors are usually communicated through a series of audible beeps. The numbers
on the fatal error list (on the following page) correspond to the number of beeps for the
corresponding error. All errors listed, with the exception of Beep Code 8, are fatal errors.
BIOS Error Beep (POST) Codes
Beep Code Error Message Description
1 short Refresh Circuits have been reset (Ready to power up)
5 short, 1 long Memory error No memory detected in system
5 long, 2 short Display memory read/write error Video adapter missing or with faulty memory
1 long continuous System OH System overheat condition
A-2 Additional BIOS POST Codes
The AMI BIOS supplies additional checkpoint codes, which are documented online at http://
www.supermicro.com/support/manuals/ ("AMI BIOS POST Codes User's Guide").
When BIOS performs the Power On Self Test, it writes checkpoint codes to I/O port 0080h.
If the computer cannot complete the boot process, a diagnostic card can be attached to the
computer to read I/O port 0080h (Supermicro p/n AOC-LPC80-20).
For information on AMI updates, please refer to http://www.ami.com/products/.

Supermicro SuperServer E300-8D Specifications

General

Stepping	V2
Scalability	1S
Processor code	SR2DN
Processor cache	6 MB
Processor cores	4
Processor model	D-1518
System bus rate	- GT/s
Processor series	Intel Xeon D-1500
Processor socket	BGA 1667
Processor threads	8
Processor codename	Broadwell
Processor frequency	2.2 GHz
Processor cache type	L3
Processor lithography	14 nm
Processor manufacturer	Intel
Processor package size	37.5 x 37.5 mm
Processor boost frequency	The turbo boost is an automatic, managed accelleration of the processor when one of the cores is overloaded.
Processor operating modes	64-bit
Embedded options available	Yes
PCI Express configurations	1x16, 1x4, 1x8
Supported instruction sets	AVX 2.0
Thermal Design Power (TDP)	35 W
Number of processors installed	1
Maximum number of PCI Express lanes	32
Memory types supported by processor	DDR3-SDRAM, DDR4-SDRAM
Memory voltage supported by processor	1.2 V
Memory channels supported by processor	Dual
Memory clock speeds supported by processor	1600, 1866, 2133 MHz
Maximum internal memory supported by processor	128 GB
Processor ARK ID	91201
Intel® Turbo Boost Technology	No
Intel Secure Key Technology version	1.00
Internal memory	- GB
Memory clock speed	- MHz
Internal memory type	DDR4-SDRAM
Flash memory	128 MB
Graphics card	AST2400
HDD size	- \
RAID levels	0, 1, 5, 10
HDD interface	-
Supported HDD sizes	2.5 \
Total storage capacity	0 GB
Maximum storage capacity	- TB
Number of HDDs installed	0
Supported storage drive interfaces	M.2, Serial ATA III
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	6
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
LAN controller	Intel I350-AM4, Intel i210
Ethernet interface type	Gigabit Ethernet
BIOS type	AMI
Trusted Platform Module (TPM) version	2.0
Bundled software	Intel Node Manager, IPMI 2.0, KVM LAN, NMI, SUM, SuperDoctor 5, Watch Dog
PCI Express slots version	2.0, 3.0
Certification	RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	8 - 90 %
Chassis type	Mini (1U)
Harmonized System (HS) code	84714100

Weight and Dimensions

Depth	226 mm
Width	254 mm
Height	43 mm
Weight	1560 g
Package depth	142 mm
Package width	381 mm
Package height	276 mm
Package weight	3400 g
