21
Chapter 2 Maintenance and Component Installation
Solid State Storage
This motherboard supports two internally mounted solid state storage cards:
• One mini-PCIe mSATA slot
• One M.2 slot supporting SATA
Figure 2-2. Installing a Mini-PCIe mSATA Card and an M.2 Card
M.2
Mini-PCIe
