Chapter 1: Introduction
Connector Description
JTPM1 Trusted Platform Module (TPM)/Port 80 Connector
LAN1-LAN8 Gigabit Ethernet (RJ45) Ports LAN1-LAN6
10Gigabit Ethernet (SFP+) Ports LAN7-LAN8
M2-SRW1 - M2-SRW3 M.2 Mounting Screws
MP-SRW1 - SRW2 PCI-E 2.0 X1 / I-SATA5 Slot Mounting Screws
SLOT6, SLOT7 CPU PCI-E 3.0 x8 Slot
UID Unit ID Button
USB 0/1 Back panel USB 3.0 Ports
USB 2 USB Type-A Connector
USB 3/4, 5/6
Front Access USB 2.0 Ports
VGA Back panel VGA Port
LED Description Color/State Status
LED3 Power LED Green: On System Power On
LED7 UID Switch LED Blue: On
LED8 Overheat/PWR Fail/
Fan Fail LED
Red: Solid on/Blinking Solid On: Overheat,
Blinking: PWR Fail or Fan Fail
LEDM1 BMC Heartbeat LED Green: Blinking BMC: Normal
LEDT1 LAN7 Link Status Green: On 10G is linked up
LEDT2 LAN7 Activity Green: Blinking 10G LAN7 is active
LEDT3 LAN8 Link Status Green: On 10G is linked up
LEDT4 LAN8 Activity Green: Blinking 10G LAN8 is active
