Supermicro X11SPM-F User Manual

3
Preface
Preface
About This Manual
This manual is written for system integrators, IT technicians and knowledgeable end users.
It provides information for the installation and use of the X11SPL-F motherboard.
About This Motherboard
The Supermicro X11SPL-F motherboard supports an Intel® Xeon 81xx/61xx/51xx/41xx/31xx
series (Socket P0-LGA 3647) processor with up to 28 cores and a thermal design power (TDP)
of up to165W. Built with the Intel PCH C621 chipset, the motherboard supports 6-channel,
8-DIMM DDR4 ECC RDIMM/LRDIMM memory with speeds of up to 2666MHz. It features
such technologies as the Intel Virtualization Technology for Directed I/O for improved security
and system reliability. The X11SPL-F includes PCI-Express 3.0 slots, SATA 3.0 ports, dual 1G
Base-T LAN support, and an M.2 slot (Type 2280 and 22110). This motherboard is ideal for
I/O intensive application and video surveillance. Please note that this motherboard is intended
to be installed and serviced by professional technicians only. For processor/memory updates,
please refer to our website at http://www.supermicro.com/products/.
Conventions Used in the Manual
Special attention should be given to the following symbols for proper installation and to prevent
damage done to the components or injury to yourself:
Warning! Indicates high voltage may be encountered while performing a procedure.
Warning! Indicates important information given to prevent equipment/property damage
or personal injury.
Important: Important information given to ensure proper system installation or to
relay safety precautions.
Note: Additional Information given to differentiate various models or provides infor-
mation for proper system setup.

Supermicro X11SPM-F Specifications

General

COM ports quantity	2
USB 2.0 ports quantity	6
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	5
Maximum LRDIMM memory	384 GB
Supported RDIMM clock speeds	1600, 1866, 2133, 2400, 2666 MHz
Supported RDIMM module capacity	4GB, 8GB, 16GB, 32GB
Supported DIMM module capacities	4GB, 8GB, 16GB, 32GB, 64GB, 128MB
Supported LRDIMM module capacity	32GB, 64GB
ECC	Yes
Memory voltage	1.2 V
Maximum RDIMM memory	192 GB
Supported memory types	DDR4-SDRAM
Maximum internal memory	768 GB
BIOS type	UEFI AMI
ACPI version	6.0
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA III
On-board graphics card model	Aspeed AST2500
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 60 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 85 %
Processor socket	LGA 3647 (Socket P)
Processor manufacturer	Intel
Processor thermal power (max)	165 W
Processor number of cores supported	28
Wi-Fi	No
Number of SATA III connectors	12
PCI Express x16 (Gen 2.x) slots	0
Sustainability certificates	RoHS
Motherboard chipset	Intel® C621
Motherboard form factor	micro ATX
Harmonized System (HS) code	84733020

Weight and Dimensions

Width	243.8 mm
