Supermicro X11SPM-F User Manual

8
X11SPL-F User's Manual
Main Parts List
Description Part Number Quantity
Supermicro Motherboard X11SPL-F 1
I/O Shield MCP-260-00109-0N 1
SATA Cables CBL-0044L 6
Quick Reference Guide MNL-1950-QRG 1
Chapter 1
Introduction
Congratulations on purchasing your computer motherboard from an industry leader.
Supermicro motherboards are designed to provide you with the highest standards in quality
and performance.
In additon to the motherboard, several important parts that are included in the retail box are
listed below. If anything listed is damaged or missing, please contact your retailer.
1.1 Checklist
Important Links
For your system to work properly, please follow the links below to download all necessary
drivers/utilities and the user’s manual for your server.
• Supermicro product manuals: http://www.supermicro.com/support/manuals/
• Product drivers and utilities: ftp://ftp.supermicro.com
• Product safety info: http://www.supermicro.com/about/policies/safety_information.cfm
• If you have any questions, please contact our support team at: support@supermicro.com
This manual may be periodically updated without notice. Please check the Supermicro website
for possible updates to the manual revision level.

Supermicro X11SPM-F Specifications

General

COM ports quantity	2
USB 2.0 ports quantity	6
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	5
Maximum LRDIMM memory	384 GB
Supported RDIMM clock speeds	1600, 1866, 2133, 2400, 2666 MHz
Supported RDIMM module capacity	4GB, 8GB, 16GB, 32GB
Supported DIMM module capacities	4GB, 8GB, 16GB, 32GB, 64GB, 128MB
Supported LRDIMM module capacity	32GB, 64GB
ECC	Yes
Memory voltage	1.2 V
Maximum RDIMM memory	192 GB
Supported memory types	DDR4-SDRAM
Maximum internal memory	768 GB
BIOS type	UEFI AMI
ACPI version	6.0
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA III
On-board graphics card model	Aspeed AST2500
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 60 °C
Storage relative humidity (H-H)	10 - 95 %
Operating relative humidity (H-H)	10 - 85 %
Processor socket	LGA 3647 (Socket P)
Processor manufacturer	Intel
Processor thermal power (max)	165 W
Processor number of cores supported	28
Wi-Fi	No
Number of SATA III connectors	12
PCI Express x16 (Gen 2.x) slots	0
Sustainability certificates	RoHS
Motherboard chipset	Intel® C621
Motherboard form factor	micro ATX
Harmonized System (HS) code	84733020

Weight and Dimensions

Width	243.8 mm
