15
Chapter 1: Introduction
Motherboard Features
Power Management
•
ACPI power management
• Power button override mechanism
• Power-on mode for AC power recovery
• Wake up on LAN
System Health Monitoring
•
Onboard voltage monitoring for +3.3 V, +5 V, +12 V, +3.3 VStb, +5 Vstb, Vcore, Vmem, CPU temperature, PCH temperature,
system temperature, memory temperature, peripheral temperature
• 6 CPU switch phase voltage regulator
• CPU thermal trip support
• Platform Environment Control Interface (PECI)/TSI
Fan Control
•
Fan status monitoring
• Dual cooling zone
• Four 4-pin fan headers
System Management
•
Trusted Platform Module (TPM) support
• Chassis intrusion header and detection
LED Indicators
•
CPU/System Overheat LED
• Power/Suspend state LED
• Fan Fail LED
• UID/Remote LED
• LAN Activity LED
• HDD Activity LED
Dimensions
•
mini-ITX, 6.7" (W) x 6.7" (L) (193.04 mm x 193.04 mm)
Note: The CPU maximum thermal design power (TDP) is subject to chassis and
heatsink cooling restrictions. For proper thermal management, check the chassis and
heatsink specications for proper CPU TDP sizing.
