29
Chapter 2: Installation
2.4 Memory Support and Installation
Note: Check the Supermicro website for recommended memory modules.
Important: Exercise extreme care when installing or removing DIMM modules to pre-
vent any possible damage.
Memory Support
The X13SCL-IF motherboard supports up to 64 GB of DDR5 ECC UDIMM memory with
speeds of up to up to 4800 MT/s (with the one or two DIMM(s) per channel congurations)
in two memory slots. Refer to the table below for the recommended DIMM population order.
1 CPU, 4 DIMM Slots
Number of DIMMs Memory Population Sequence
1
DIMMB1
DIMMA1
2 DIMMB1 / DIMMA1
Memory Support
DIMM Type Speed (MT/s) DIMM Slots
1R UDIMM 4800 DIMMA1, DIMMB1
2R UDIMM 4800 DIMMA1, DIMMB1
