P8SC8/P8SCi User's Manual

4-12

4-4.5 Hardware Monitors

There are only three settings on this menu (below). The rest of this

menu shows various temperatures and voltage levels as indicated.

Onboard LAN Boot ROM

This feature allows the user to determine if the Boot ROMs of the Onboard

LAN chips should be activated. If activated, the user can boot the system

from the Onboard LAN chips. The options are Disabled, LAN1, LAN2 and

Both.

Maximum Payload Size

This setting allows the BIOS to set the maximum TLP Payload size for the

PCI Express devices in the system. The options are: "128 (bytes)", "256

(bytes)", "512 (bytes)", "1024 (bytes)", "2048 (bytes)", and "4096 (bytes)".

XPCI Express Root Port Function

PCI Express Port 1/PCI Express Port 2/PCI Express Port 3/PCI

Express Port 4

Select "Enabled" to enable the PCI Express Root Port Functions for the

PCI Express port specified. The options are: "Disabled", "Enabled", and

"Auto".

PCI-E Compliance Mode

This features allows the BIOS to set the version of PCI-E Compliance

Mode for the system. The options are: "v.1.0a" and "v.1.0".

PCI-X Frequency

This features allows the user to configure the default setting for PCI-X

Frequency. The options are: "Auto, PCI-33 MHz, PCI-66 MHz, PCIX-66 MHz,

PCI-X 100 MHz, PCI-X 133 MHz."
