Supero X10SLQ User Manual

1-8
X10SLQ/X10SLQ-L User’s Manual
One (1) mini-PCI-Express socket shared with mSATA (Not
available on the -L model).
Video and Graphics
One (1) High Denition Multimedia Interface (HDMI), one
(1) DisplayPort, one (1) DVI-D, and one (1) VGA from Intel
Processor Graphics, support three independent Displays.
Audio
One (1) High Denition Multimedia Interdace (HDMI),
one (1) DisplayPort, and one (1) High Denition Audio
7.1 channel connector on the back panel.
One (1) Front Panel Audio Header
Super I/O
Nuvoton NCT6776D
BIOS 128 Mb AMI BIOS
®
SPI Flash BIOS
Play and Plug, PCI 2.3, ACPI 4.0a, UEFI 2.3.1, USB Key-
board and SMBIOS 2.7
Power Conguration ACPI/ACPM Power Management
Main Switch Override Mechanism
Keyboard Wake-up from Soft-Off
External Modem Ring-On or USB 0/1, 6/7 Wake-up from
S3/4/5
Power-on mode for AC power recovery
PC Health Monitoring CPU Monitoring
Onboard voltage monitors for VCCP, VCC3_3, AVCC,
VCC3_3_ALW, VBAT, VCC12, V_DIMM, VCC5 and
VCC1P05_PCH
CPU 3-phase switching voltage regulator
CPU/System overheat LED and control
CPU Thermal Trip support
Adaptive Thermal Monitor support
Fan Control
Fan status monitoring with rmware 4-pin fan speed
control
Low noise fan speed control
System Management PECI (Platform Environment Conguration Interface) 3.0
support
System resource alert via SuperDoctor® III
SuperDoctor® III, Watch Dog, NMI, AMT 9.0
Chassis Intrusion header and detection
