1-4
X8DTU/X8DTU-F User's Manual
X8DTU/X8DTU-F Quick Reference
Notes:
Jumpers not indicated are for test purposes only. 1.
See Chapter 2 for detailed information on jumpers and connectors2.
" " indicates the location of Pin 1.3.
When LE1 LED is on, the onboard power connection is on. Make sure to 4.
unplug the power cables before removing or installing components.
IPMI (Intelligent Platform Management Interface) 2.0 is supported by the 5.
X8DTU-F. For more information on IPMI confi guration, refer to the Embedded
BMC IPMI User Guide @http://www.supermicro.com/support/manuals/.
Warning! To prevent damage to the power supply or motherboard, please
use a power supply that contains a 20-pin and two 8-pin power connec-
tors. Be sure to connect these connectors to the 20-pin (JPW1) and the
two 8-pin (JPW2,JPW3) power connectors on the motherboard. Failure in
doing so will void the manufacturer warranty on your power supply and
motherboard.
KB/MS
Fan8
(CPU1Fan)
IPMI LAN
USB 0/1
COM1
PHY
VGA
LAN1
LAN2
LAN CTRL
BMC CTRL
BIOS
COM2
USB6
USB7
USB4/5
JTAG Of CPLD
JPI2C
P1-DIMM3A
P1-DIMM3B
P1-DIMM2A
P1-DIMM2B
P1-DIMM1A
P1-DIMM1B
P2-DIMM1B
P2-DIMM1A
P2-DIMM2B
P2-DIMM2A
P2-DIMM3B
P2-DIMM3A
LE2
JUIDB
JPL1
J10
UIOP
SXB2: PCI-E 2.0 x 8
SXB1: PCI-E 2.0 x 16
SXB3: PCI-E 2.0 x 8 in x 4 Slot
J1
J2
J3
JPG1
Fan6
IPMB
JI2C1
JBT1
J13
J14
J12
Fan5
JL1
USB2/3 JLPC1
CPU2
CPU1
Intel 5520
IOH]
Intel ICH10R
South Bridge
T-SGPIO2
T-SGPIO1
J17
JWD
JF1
JOH1
LE1
Fan4
Fan3
SP1
Buzzer
JBAT1
Battery
Fan2
Fan1
JPW1
JPW3
JPW2
JD1
I-SATA5
I-SATA4
I-SATA3
I-SATA2
I-SATA1
I-SATA0
X8DTU/-F
Fan7(CPU2 Fan)
FP CTRL
CPLD
PWRLED/SPK
Rev. 2.01
JPB
JI2C2
JP3
