2-16
X8DTU/X8DTU-F User's Manual
X8DTU/-F
Rev. 2.01
1
VGA
Connector
A
VGA
connector is located next to
COM Port1 on the IO backplane. This
connector provides video and CRT
display
. Refer to the board layout
below for the location.
VGA/CRT Pin
De
fi
nitions
Pin# De
fi
nition
Pin# De
fi
nition
1
Red
10
Ground
2
Green
1
1
MS0
3
Blue
12
MS1: SDA
(DDC Data)
4
MS2
13
HSYNC
5
Ground
14
VSYSNC
6
Ground
15
MS3: SCL
(DDC CLK)
7
Ground
16
Case
8
Ground
17
Case
9N
C
NC= No Connection
1. VGA
