Chapter 1: Introduction
1-7
Chassis intrusion detection•
System resource alert via Supero Doctor III•
ACPI Features
Slow blinking LED for suspend state indicator•
Main switch override mechanism•
ACPI Power Management•
Keyboard Wakeup from Soft-off •
Onboard I/O
Intel ICH10R supports six SATA ports (with support of RAID0, RAID1, RAID10, •
RAID5 in the Windows OS Environment, and RAID 0, RAID 1, RAID 10 for the
Linux OS)
Intel 82576 dual-channel Gigabit Ethernet controller supports dual Giga-bit
•
LAN ports (LAN 1/LAN 2)
A PHY chip supports an IPMI_Dedicated LAN on the X8DTU-F
•
One VGA Port supported by the Winbond WPCM450 BMC Controller•
Two COM ports(1 header, 1 port)•
PS/2 mouse and PS/2 keyboard ports•
Up to eight USB 2.0 (Universal Serial Bus) (2 Rear Ports, 2 Front Headers, •
and 2 Type A Headers)
Super I/O: Winbond W83527HG
•
IPMI 1.5/2.0 with full KVM support (X8DTU-F only) •
Note: IPMI 1.5/2.0 is supported by the X8DTU-F. For more information on
IPMI confi guration, refer to the Embedded BMC IPMI User Guide @http://
www.supermicro.com/support/manuals/.
Other
Console redirection•
Onboard Fan Speed Control by Thermal Management via BIOS•
CD/Diskette Utilities
BIOS fl ash upgrade utility and device drivers•
Dimensions
Proprietary 13.05" (L) x 12.075" (W) (331.47 mm x 306.71 mm)•
