6. Technical Specications
Power supply
Supply voltage: 230 V ~ / 50 Hz
Nominal power: 70 W
Consumption: Standby: < 0.5 W
Mechanical capacity
Nominal torque: 8 Nm
Maximum speed: 36 rpm
Maximum tractive force:
30 kg, see page 39 /
Tractive force diagram
End tractive force: 13 kg
Operating conditions
Transient operation (KB):
4 minutes
(maximum running time)
Protection class: II
Protection type:
IP20 (only for use in dry rooms)
Number of switching times: 2 (up and down)
Mains connecting cable: 2 x 0.75 mm
2
(H03VVH2-F)
Permissible ambient tem-
perature:
0 °C to +40°C
Sound pressure level (LpA): ≤ 70 dB(A)
Conduct in the event of power failure
The indicator light ashes in the event of a power failure.
The ashing is switched o by pressing the UP ( ▲ ) or
DOWN ( t ) button.
Data retention following a power failure
The configured switching times are retained after a
power failure. As soon as the power supply is restored,
the opening and closing times will be executed again.
However, the times will be oset by the duration of the
power failure.
Example:
◆ Power failure from 19:30 - 19:45 hours.
◆ The closing time was previously set to 19:30 hours.
◆ The roller shutters will close at 19:45 hours due to
the duration of the power failure.
