22. Tractive force diagram
1
Lifting weight [Kg]
2
Belt thickness 1.0 mm
3
Belt thickness 1.3 mm
4
Belt thickness 1.5 mm
5
Belt length [m]
i
1
5
2
3
4
Belt length [ m ]
Lifting weight [ kg ]
