6.2 Permissible roller shutter belts
i
ATTENTION!
The superrollo GW180 / GW185 may be damaged
if excessively long belts are used.
Only use belts of the permissible lengths.
Table 1: Permissible roller shutter belts
superollo:
Item No.:
GW185 (Mini Belt)
SR10185
GW180
SR10180
Belt width:
Belt thick-
ness
Maximum belt length
15 mm (Mini-belt) 1.0 mm 5 m
23 mm (Standard belt)
1.0 mm 5 m
1.3 mm 4 m
1.5 mm 3.4 m
Table 2: Permissible shutter surface area (m
2
)
Roller shutter type: Weight/m
2
Permissible shutter surface area (m
2
)
Plastic roller shutters (4.5 kg/m
2
) Approx. 5 m
2
Approx. 5 m
2
Aluminium and wooden roller shutters (10.0 kg/m
2
) Approx. 2.5 m
2
Approx. 2.5 m
2
i
The specications are intended for guidance
only and apply to an ideal installation
situation.
The actual values may vary due to local
conditions.
