22
EN
i
10. Mounting the wall bracket
i
The letterings "TOP and OBEN" on the wall
bracket indicates the correct mounting posi-
tion.
i
Use the correct type of screw depending on
the mounting surface, see the 'included in
delivery' section on page 7.
◆ Wall mounting = 4 x 40 mm
◆ Mounting onto window
frame = 4.2 x 19 mm
4. Screw on the wall bracket with the screws provided and
ensure that the right side is facing upwards (OBEN/TOP).
Indication of the correct mounting
position on the wall bracket.
Correct
mounting of
the wall bracket.
