24
EN
4. Next, draw-in the belt into the superrollo GW180 / GW185
from the top.
Feed the belt into the device, as shown in the image,
and slide it over the Fastening hook from below.
5. Re-insert the mains plug into the socket.
6. Press the up button until the belt has fully
wound once around the reel.
7. Pull the belt tight when winding, so that the deection
roller turns at the same time.
8. Remove the mains plug again from the socket.
9. Finally, place the provided reel compartment cover onto
the reel compartment.
11. Drawing in and fastening the belt
Reel compart-
ment cover
Belt path
in the device
i
Pull the belt over the Fastening
hook from below
