4. If the distance between barrier and the edge is more than 1.5 meters, surround it
as ringlike island.
1.3.7 fix the fence line when there are multi-area
As to multi-area lawn, if the sum area is within 1800 square meters, paths between
areas is at the same level with the lawn or less than 3 centimeters in height or more
than 2 meters width pathway, you may use fence line as ringlike island or peninsula
to surround it. The mower can cross through freely.
The width should not be less than 2m Flush with or higher than lawn(within 3 cm)
Figure 1.3.7
1.4 Install intelligent navigation workstation
1.4.1 Place the base of workstation on the pre-chosen place. Adjust its position
according to needs. Use a shovel to make signs alongside the brick of the base. Use
the shovel to clean the grass of the fix position. Then move the surface soft earth
away and make it even and solid. Try to make the surface of the base is at the same
level of the lawn. Put the base at the pre-chosen position, facing the fence line in the
anti-clockwise direction. Then adjust its position carefully.(see Figure 1.4.1 A)
Figure 1.4.1A Figure 1.4.1B
● The front fence edge must cross the bottom of the base to the back of the
workstation and have 20 centimeters free to connect the fence plug.
● The front fence line before the navigation station must have more than two
meters running vertically , and perpendicular to the center of the front
chassis, ensure return accurately to charge station.
