● The back end should be pulled to the back of the workstation. Use spear-pin
to fix the connection of the front and the back end. The back end should have
20 centimeters free to connect the fence plug.(see Figure 1.4.1 B)
1.4.2 Use the preset plastic spear-pin to fix the base of the intelligent navigation
workstation.(see Figure 1.4.2 A)
Figure 1.4.2 A Figure 1.4.2 B
Attention: The intelligent navigation workstation must be fixed on even solid
ground, facing the fence line in anti-clockwise direction (see Figure 1.4.2 B). There
are smooth path on the lawn for the mower to move on. The base must be stable, in
case of the mower's rolling over when climbing up to charge, wait or shelter from
rain.
Warning! It may cause damage to eyes and hands. When fixing, please
mask yourself with gloves and eye-shield measures in case of injury from the pine
broken down or the flying earth.
1.4.3 fix the cover of the intelligent navigation workstationFix the cover on the
base. Use screw to secure it from the back.(see Figure 1.4.3)
Figure 1.4.3
15
←
←
!
