4.1 Applicable power supply
The standard charger with the Intelligent Mower can charge the rechargeable
battery in the machine. Connect the power cable of charger to eligible in-door
electric socket, and charge the battery by 110V~230V AC, the output is 24 V DC.
The output terminals are connected to the installed Intelligent navigation
workstation. (As shown in Figure 4.1 A)
Figure 4.1 A
The normal charging time is 8 hours, once finished, the Intelligent Mower will
automatically move backward for 10 cm to detach the front-end charging bar from
the electrode slices on the Intelligent navigating workstation, and make peep sound.
The light on the charger and intelligent navigating workstation will turn from red to
green, and stand by until next time. To ensure good performance and life time of the
battery, charging is an important aspect, special warning and power management
system is integrated into the Intelligent Mower in case of improper charge.
Warning! Electric shock is dangerous, injury or death may occur. The
charger of Intelligent Mower is only designed for the use in dry in-door places; DO
NOT left the charger at extreme wet place or exposure it to humidity. The charger
should be fixed at appropriate place inside the house, and connect the output cable
to the interface of Intelligent navigating workstation. If the electrodes are damaged,
it is prohibited to charge. Please strictly use suited charger to the Intelligent Mower,
and keep hands dry when inserting the plug.
22
Navigating station socket
Output cable plug
Output cable
Plug
Charger
!
Chapter Four Power supply use management
